Appion G 5 Twin Refrigerant Recovery Machine



He appion two stage vacuum pump for hva/r work

the choice is clear withthe tez-8 appion brings innovative,advanced technology to the vacuum pump designed from the ground up the tez-8 combines performance and reliabilty with user friendly features to save you time and money

trade marked 5 second oil change

with the introduction of the tez-8 vacuum pump oil management has becombe simple ..Thanks to ‘tezom’ technology (totally e z management) the replacable ‘tezom’ cartridge is the oil supply and oil sump all in one

the ‘tezom’ cartridge is clear,making it easier than ever to monitor the condition of the oil ,and you can change cartridges in about 5 seconds..Dirt and sludge trapped in the ‘tezom’ cartridge is removed when the cartridge is changed this helps you ensure your vcacuum is always pulling a rapid and deep vacuum

unlike other oil cooled pumps the tez-8 is air cooled by a custom high speed turbine fan blasting cool air over the entire assembly,eliminating the need for excessive oil capacity..With so much cooling power the pump runs cooler and lasts longer so that high ambient environments (rooftops hot mechanical rooms etc) will not slow this down,and the case stays cool to the touch making handling safer and easier

tez-8 specifications

length 362mm height 262mm width 239mm weight 12.7kgs

power 240v50hz 10amps also available 115v 60hz 10amps

free air displacement 8cfm

ultimate vacuum
